Compact 3PDT Wiring PCB
AUD $2.20
0 Units in Stock
Dimensions: 22mm x 16mm
Compact 3PDT wiring PCB
Fabricatored 3PDT Mounting PCB. Contains pads for the LED current limiting resistor and elimates a few extra wire connections for a neater build. Very compact in size! Compatible with all standard sized PCB Mount or solder lug 3PDT footswitches. May not fit some "compact" style 3pdt footswitches.
Compact 3PDT PCB - Example Wiring Diagram
Abbreviations
R1 - CLR
Current Limiting Resistor for the LED
InJShd
Input Jack Shield
InJTip
Input Jack Tip
InPCB
PCB Input
LED-
LED minus
OutPCB
PCB Output
OutJTip
Output Jack Tip
Using the Compact 3pdt PCB
