Power Inverter for Fuzz Pedals
AUD $5.00
Please Choose:
Kit Options
Add PCB Components ( +AUD $4.50 )
Add Miniature DC Jack ( +AUD $3.80 )
Add to Cart:
3 Units in Stock
Difficulty Level
Novice
Not sure what parts to order? Learn more in
this short video
Power Inverter for Fuzz Pedals
Very compact (approximantely only 2x2cm) this board will flip your +9v input to -9v output, to power positive ground effects, such as PNP germanium transistor boost and fuzz pedals (rangemanster, fuzz face, tonebender, etc).
Dimensions: 20mm x 19mm
*** Base price is for PCB only, please select kit options above to order kit components
Kit Options
• Kit Components
"Kit Components" includes all onboard components you need to build the "Power Inverter" including a TC1044SCPA.
• Miniature DC Jack
These DC jacks are very small and are suitable for any build not using a battery / battery switching. Especially good for 1590a builds as they are compact in size!
Downloads
Bill of Materials
