Boy in Well - Simple Delay

***new** Boy in Well - Simple Delay

Note: This is a pcb only project. PCB color may vary


A simple DIY project featuring the ever popular delay chip, the PT2399. Boasting up to 600ms of delay time with a respectable "vintage" tone, the Boy In Well Delay features 3 dial controls, Time, Level and Repeats and is a well suited delay project for the beginner.

The boy in well is an affordable DIY delay and is suited to a 1590B and can be built with common "off the shelf" parts.

PCB Sizing: 1590B enclosure (with some planning) otherwise 125b.



Downloads
Build Doc and Schematic



Boy in Well Videos
