Classic Boost - LPB1 Inspired Tone Controlled Boost
A simple compact boost with an impressive boost range, the Classic Boost is based on the classic booster, the LPB1. An Included modification is an input capacitor blend tone control (can also be easily bypassed) enabling the classic boost to also act as a frequency booster. This project is an easy fit for a 1590a enclosure (9mm pots) and supports pcb mounting of 9mm alpha pots.
Dimensions: 21mm x 20mm
PCB Sizing: 1590a enclosure (no-special hardware required) or larger
*** Base price is for PCB only, please select kit options above to order kit components
Kit Options
Please select the kit options you would like included with your PCB from the checkboxes above
• PCB Components
"PCB Components" includes all onboard components you need to build the "Classic Boost". Battery snap is included as well as 6 lenghts of wire. Also includes, LED, current limiting resistor ("medium" brightness) and plastic bezel for mounting the led to an enclosure.
• 9mm Potentiometer
Add 9mm Alpha metal shaft potentiometers to your kit!
• Mono Jacks (2 of)
!! Due to stock scarcity Nuetrik mono jacks may be sent in place of lumberg mono jacks !!
"Compact Mono Jacks (2of)" include 2 Lumberg compact mono jacks with your kit. These jacks are small in size, a good choice for tight builds and beginners but can be used for any build. Please note you will need a stereo jack if you plan to power your effect with a battery. (Stereo jacks are available in the hardware section of this store).
• Miniature DC Jack
These DC jacks are very small and are suitable for any build not using a battery / battery switching. Especially good for 1590a builds as they are very compact.
• Knobs
1900H Davies Clone Knob
What else do i need to complete this project?
You will need an enclosure and a 3pdt footswitch to complete this project, if you order all available kit component options above.
